Agri Implement
Durable agricultural implement tyres designed for superior load support, soil protection, and reliable performance in demanding farming and field operations.
Special Application
Agri Implement
›
Low section profile
This design helps in lesser soil compaction
›
Special design
Aids in drive and free rolling wheels
›
Higher load capacity
Strengthened casing provides load capacity
Technical Specifications
| Size | Rim (inch) | Alternate Rim (inch) | Inflated Dimensions (mm) +/-2% OD | Inflated Dimensions (mm) +/-2% CROSS SW | Inflated Dimensions (PLY Rating) | Load Capacity (kg) 30 kmph HLV | IP (bar) 30 kmph HLV | Load Capacity (kg) 40 kmph HLV | IP (bar) 40 kmph HLV |
|---|---|---|---|---|---|---|---|---|---|
| 10.0/80 -12 | TL | 9 | 710 | 270 | 8 | 1500 | 4.2 | 1250 | 4 |
| 10.0/75 -15.3 | TL | 9 | 760 | 264 | 10 | 1800 | 5 | 1550 | 5.1 |
| 11.5/80 -15.3 | TL | 9 | 850 | 290 | 12 | 2575 | 5.5 | 2180 | 5.3 |
| 12.5/80 -15.3 | TL | 9 | 890 | 305 | 14 | 3075 | 5.7 | 2650 | 5.6 |
